Bestech Power 7S Lipo BMS 25A, 25A 24V BMS for Lipo Battery Packs
- 2022-12-19 -
Bestech Power 7S Lipo bms 25A,BMS 25A 24V for Lipo battery packs:
| Content | Spec | Unit | Remark | ||||
| 25A | 35A | 45A | 60A | ||||
| Discharge | constant discharge current | 25 | 35 | 45 | 60 | A | |
| peak discharge current | 60 | 100 | 180 | 180 | A | ||
| Over current protection | 60 | 100 | 180 | 180 | A | ||
| charge | charge voltage | Series *4.2V | V | ||||
| charge current | 25A | 35A | 45A | 60 | A | 8A for separate prot | |
| Over charge protection | over charge volt | 4.25±0.025 | V | ||||
| over charge volt protect delay | 0.5 | S | |||||
| Over charge volt release | 4.19±0.05 | V | |||||
| Power balancing | Power balance volt | 4.18 | V | ||||
| balance release volt | 4.18 | V | |||||
| balance current | 35±5 | mA | |||||
| Over discharge protection | Over discharge detect volt | 2.8±0.05 | V | ||||
| Over discharge detect delay | 0.5 | S | |||||
| Over discharge volt release | 3.0±0.05 | V | |||||
| Over current protection | Over current detect volt | 150 | mV | ||||
| Over current detect delay | 9 | MS | |||||
| Over current protect release | off load | ||||||
| Short circuit protection | Short circuit protection | short circuit of external board | |||||
| Short circuit detect delay | 250 | uS | |||||
| Short circuit detect release | off load | ||||||
| Temperature protection | Temp protection | none | ℃ | Can be customized | |||
| resistance | Main circuit resistor | ≤10 | mΩ | ||||
| Self-consumption | Working current | ≤40 | uA | ||||
| Sleepy current(when battery is over discharged ) | ≤20 | uA | |||||
| Working temp | temp range | -30~80 | ℃ | ||||
